KITO SEM Mini Electric Chain Hoist (225-450kg)

CAPACITY

• 225-450kg

STANDARDS

• Standard lift 10′
• 1 year warranty (from defects in material and workmanship)

RATINGS/CLASSIFICATIONS

• UL1340
• CSA 22.2 No.33
• ASME B30.16
• ANSI E 1.6-2
• Hoist — IP65

OPTIONS

• Canvas chain container
• Longer lift or pendant lengths

BODY

• Sleek rounded body with rugged aluminum housing and no sharp edges
• Completely sealed and suitable for both indoor and outdoor applications, including harsh environments

SOLID STATE RELAY BOARD

• Has no mechanical contacts for extended lifetime
• Microcontroller provides protection from fast reverse, phase loss and reversal, overcurrent, overtemperature, and overvoltage
• Includes electronic overload limiter and LED error indicator

GEARS

• Grease-Packed Gearbox for demanding theatrical applications
• Maintenance free
• No oil changes required

LOAD CHAIN

• Nickel-plated load chain
• Grade 80
• Meets DIN and EN 818-7 standards.

CHAIN GUIDE

• Prevents tangling when winding up slack chain
• Provides quiet and smooth guiding of chain
• Heat treated for durability

HOOKS

• Forged carbon steel opens gradually without fracturing under excessive loads.
• Top and bottom hook swivel 360°
• Bottom hook will swivel 360°
• Fixed top hook
• Prevent twists in rigging
• Heavy duty hook latches

BRAKE

• 5 year warranty
• Electromagnetic brake
• Simple design: no brake coil to fail or brake disc to replace

OVERLOAD PROTECTION

• Rotor integrated friction clutch outside the load path
• Protects hoist from damage and prevents overwinding
• Provides consistent performance over a wide temperature range

OVERTRAVEL PROTECTION

• Low profile upper/lower limit switches need no adjustment
• Protects hoist and allows for maximum travel
